KRISHANA INK & SERVICES

Inkjet Printing Machine

KRISHANA is an indian brand, offers you a variable data coding solutions to apply identification marking such as variable dates, traceability codes, logos and batch code on most of the material or surface. Quality of printing delivered using the latest automatic monitoring system, simplicity of setup, service and operation through an easy to use menu system. powerful and flexible print options. The KRISHANA gives the performance with a low cost of ownership.

Hardware Features

Service module filter change interval 6000 hours or 24 months for dye based ink.
4000 hour's or 12 months for soft pigmented inks.
Hardware configuration 4 core CPU, main frequency 1.4 GHz, standard 1GB ram.
8 GB EMMC PROTOCOL - MODBUS standard industrial protocol.
10.1 inch colour touch screen with tough solvent resistance guard.
Robust, flexible 3 meter conduit for static and moving print head applications.
Durable gear pump, separate diaphragm pumps for ink and makeup addition (3 pumps).
DIMENSION- main controller 370mm 310mm 510mm.
print head: 230mm* 44mm* 41mm*

Software Features

Can print 1 to 5 lines of print with max speed of 285m/min*
QT software 10.1 inch LVDS high resolution (1280*800) big touch screen with tough.
Solvent resistance guard, simple operation experience on new user friendly interface.
SOFTWARE UPDATE- simple remote update software with latest function.
Multi language menu and keyboard, English, Arabic, Russian, Janpanese and Persian etc.
New QT system is very easy to add any language.
WYSIWYG onscreen massage/ logo editing with drag and drop field positioning.
Dynamic massage storage (over 1,000 messages)
Real and expiration time and date, shit and rollover.
Functions product and batch counting programmable

IMPROVED HYDRAULIC SYSTEM & PRINTHEAD

Intelligent hydraulic system guarantee well- sealed ink and makeup
Throw distance 30-35mm from print head to surface.
Ease of access all the parts and print head for any service if required.
Aviation connector for photo cell, encoder and beacon.
No expensive components. No external air supply. No module and No special tool require to run or to maintain.
